Century Unit Heater Motors (HVAC/R) 732A - 1/3 HP - 115/208-230 V - 1140 RPM - Single phase
Century Unit Heater Motors (HVAC/R) 732A - 1/3 HP - 115/208-230 V - 1140 RPM - Single phase

Century Unit Heater Motors (HVAC/R) 732A - 1/3 HP - 115/208-230 V - 1140 RPM - Single phase

Century
$448.00
$448.00
Quantity must be 1 or more
  • Horsepower : 1/3
  • Amps : 4.8/2.4
  • Frequency : 60 Hz
  • Length : 6-1/2"
  • "C" Dim. : 11-5/8"
  • Enclosure : Totally Enclosed
  • Shaft Dim. : 1/2” x 4-1/2”
  • Type : Permanent Split Capacitor
  • Speeds : 1
  • Diameter : 5-5/8"
  • Bearings : Ball
  • Rotation : Reversible
  • Protector : Automatic
  • Service Factor : 1.00
  • Ambient Temp. : 60°C
  • Capacitor Rating : 5MFD-370VAC
  • Feature(s) : Class 'B' Insulation, Capacitor Mounted, Resilient Base, Includes split bushing and key for 5/8" shafts
  • Weight (lbs.) : 28
  • Reference : A.O. Smith F48Y58A01, Century 152864, 177328, C748, Dayton 3M835, Emerson K55HXHPY8817, General Electric 3J648BX, 4J392BX, Marathon 48A11T201, U.S. Motors 1900
