Century Unit Heater Motors (HVAC/R) 768A - 1/3 HP - 115/230 V - 1725 RPM - Single phase
Century Unit Heater Motors (HVAC/R) 768A - 1/3 HP - 115/230 V - 1725 RPM - Single phase

Century Unit Heater Motors (HVAC/R) 768A - 1/3 HP - 115/230 V - 1725 RPM - Single phase

Century
$494.00
$494.00
Quantity must be 1 or more
  • Horsepower : 1/3
  • Amps : 3.80 / 1.90
  • Frequency : 60 Hz
  • Length : 6-3/4"
  • "C" Dim. : 11-13/16"
  • Enclosure : Totally Enclosed
  • Shaft Dim. : 1/2” x 4-1/2”
  • Type : Permanent Split Capacitor
  • Speeds : 1
  • Diameter : 5-5/8"
  • Bearings : Ball
  • Rotation : Reversible
  • Protector : Automatic
  • Service Factor : 1.00
  • Ambient Temp. : 60°C
  • Capacitor Rating : 10MFD-370VAC
  • Feature(s) : Class 'B' Insulation, Capacitor Included, Includes Split Bushing and Key for 5/8" Shaft, Resilient Mount
  • Weight (lbs.) : 18
  • Référence :A.O. Smith F48Z68A01, S48B37B64, General Electric 3J662BAX11, Universal Electric 768, Leeson A4P17NZ94
