• HP : 50 Watt
• Voltage : 230
• RPM : 1500
• Current (Amp) : 0.85
• Phase : 1
• Rotation : Clockwise Lead End
• Frame : Unit Bearing
• Enclosure : Totally Enclosed Air Over
• Speeds : 1
• Protector : Thermally Protected
• Ambient Temp : 40°C
• Service Factor : 1.00
• Shaft Dimensions : 0.375 in X 1.6 in
• Frequency : 60Hz
• Diameter : 3.3 in
• Frame Length : 4.79 in
• Bearings : Unit
• Features : Class A Insulation, 34 in Leads, Tapped Double Boss, 3 Tapped Holes Opposite Shaft End
• Cross References : Century 260 UB50CWH, Copeland 050-0017-01 050-0244-00, Morrill EMS ESPOL50EM26 ESPOL50EM2C-C1, Rotom R5012, 998-1007-00
