US Motors Belted Fan Motors (HVAC/R) 5794C - 1/2 HP - 115 V - 1725 RPM - Single phase
US Motors Belted Fan Motors (HVAC/R) 5794C - 1/2 HP - 115 V - 1725 RPM - Single phase

US Motors Belted Fan Motors (HVAC/R) 5794C - 1/2 HP - 115 V - 1725 RPM - Single phase

US Motors
$449.00
$449.00
Quantity must be 1 or more
  • Model : 5794C
  • Horsepower : 1/2 HP
  • RPM : 1725 / 1140
  • Amps : 8.70
  • Frequency : 60 Hz
  • "C" Dim. : 10-13/32"
  • Enclosure : Open Drip-Proof
  • Shaft Dim. : 1/2" x 1-1/2”
  • Type : Split Phase
  • Speeds : 2
  • Diameter : 6-1/2"
  • Bearings : Ball
  • Rotation : Reversible
  • Protector : Automatic
  • Service Factor : 1.00
  • Ambient Temp. : 40°C
  • Feature(s) : Resilient Base, Class ‘B’ Insulation
  • Weight (lbs.) : 25
  • US Motors 5794C fan and blower motor designed for HVAC ventilation systems, air handlers and blower applications requiring a reliable 1/2 HP 115V motor.
  • Référence : A.O. Smith S56AA58A01, Bluffton Stock No. 10708, Century Stock No. SGF2054AV2, Emerson S63CXJCK7137, S63CXJCK7449, General Electric Stock No. H715, Marathon Stock No. H176
Back to 1 Phase
