Emotortek OEM Replacement Motors (HVAC/R) UFM78 - 1/10 HP - 115/230 V - 3200 RPM - Single phase
Emotortek OEM Replacement Motors (HVAC/R) UFM78 - 1/10 HP - 115/230 V - 3200 RPM - Single phase

Emotortek OEM Replacement Motors (HVAC/R) UFM78 - 1/10 HP - 115/230 V - 3200 RPM - Single phase

Emotortek
$294.00
$294.00
Quantity must be 1 or more
  • Horsepower :1/10
  • Voltage :115/230
  • Amps :1.30/0.70
  • RPM :3200
  • Frequency :60 Hz
  • Length :4-1/8”
  • Enclosure :Open
  • Shaft Dim. :5/16” x 3-1/4”
  • Type :Permanent Split Capacitor
  • Speeds :1
  • Diameter :3.3”
  • Bearings :Ball
  • Rotation :Reversible
  • Protector :Thermally Protected
  • Ambient Temp. :40°C
  • Feature(s) :Class ‘B’ Insulation, 4 Mounting Studs on Each End & No Switch
  • Weight (lbs.) :5

  • Reference : Emerson K33HXBAH454, Fasco 7162-0718 7162-0825 7162-0938 7162-4258, MacMillan 229-350/17, OmniDrive 229-482/14 P1132, Rotom RFM78, Universal Electric JE1F022N JE1F025N JE1F026N JF1E040N JF1G076N JE1G077N, Universal Stock No. 990 991
