• HP: 1/60
• Voltage: 120
• RPM: 3000
• Current (Amp): 0.75 - 0.63
• Phase: 1
• Rotation: Counterclockwise Shaft End
• Frame: Skeleton
• Enclosure: Open
• Speeds: 2
• Protector: Thermally Protected
• Ambient Temp: 40°C
• Service Factor: 1.00
• Shaft Dimensions: 0.218 in X 1.33 in
• Frequency: 60Hz
• Frame Length: 2.01 in
• Bearings: Sleeve
• Features: class b insulation, (1) 16"/14" lead with .5" strip, (1) 18"/16" lead with spade terminal, (1) 20"/18" lead with spade terminal, extended studs shaft end, thermally protected, one-shot fuse
Reference : Broan Nutone 30080011, Fasco 7158-1218 7102-1135 7102-1155 7102-2613, Rotom R610, OmniDrive SS610, Electrohome 2858-204-012 2858-204-013 2858-204-022 2858-205-017 2858-206-036 2858-206-038 2858-207-001 2858-207-002 2858-207-003 2858-207-004 2858-207-005 2858-207-007 2858-207-008 2858-207-009 2858-207-010 2858-207-011 2858-208-012 2858-209-005 2858-209-011 2858-409-009 2868-104-054
