Emotortek C Frame Motors (HVAC/R) SS610 - 120 V - 2400 RPM - Single phase
Emotortek C Frame Motors (HVAC/R) SS610 - 120 V - 2400 RPM - Single phase

Emotortek C Frame Motors (HVAC/R) SS610 - 120 V - 2400 RPM - Single phase

Emotortek
Sold out
$57.00
Quantity must be 1 or more
  • Stack :7/8"
  • Voltage :120
  • Amps :1.20 / 0.75
  • RPM :2400
  • Frequency :60 Hz
  • Enclosure :Open
  • Shaft Dim. :7/32" x 1-3/16"
  • Type :Shaded Pole
  • Speeds :2
  • Frame :Skeleton
  • Bearings :Sleeve
  • Rotation :CCWSE
  • Protector :Thermally Protected
  • Ambient Temp. :40°C
  • Feature(s) :"C" Groove on Shaft
  • Weight (lbs.) :2
  • Reference : A.O. Smith Catalogue No. C01610, Electrohome 2858-104-054 2858-204-012 2858-204-013 2858-204-022 2858-205-016 2858-205-017 2858-206-036 2858-207-001 2858-207-002 2858-207-003 2858-207-004 2858-207-005 2858-207-007 2858-207-008 2858-207-009 2858-207-010 2858-207-011 2858-207-012 2858-209-005 2858-209-011 2858-409-009, Fasco 7102-613 Broan Nutone 30080011 K6970-000, 0080011, 077980000265, 1V4217, 25002, 2789, 285810454, 285820412, 285820413, 285820422, 285820516, 285820517, 285820633, 285820636, 2858207001, 2858207002, 2858207003, 2858207004, 2858207005, 2858207007, 2858207008, 2858207009, 2858207010, 2858207011, 285820012, 285820905, 285820911, 2858409001, 285840909, 30080011, 30080012, 30080434, 5100, 52000, 6456, 64964, 65101, 675, 67846, 71022613, 7627171, 81734, 81795C00, 81798C00, 81800, 81800C00, 82230C00, 94965, C01610, EM673, EM681, EM682, EM684, EM685, HVA519, K109, K610, MODEL902C, MODEL903C, MODEL903NC, MODELH20N, MODELH25N, MODELH26N, MODELH2TN, MODELH4TN, MODELV20, MODELVK20, E264-482/40, J238-075-7162
