Fasco Fan & Blower Motors (HVAC/R) D181 - 1/30 HP - 115 V - 1500 RPM - Single phase
Fasco Fan & Blower Motors (HVAC/R) D181 - 1/30 HP - 115 V - 1500 RPM - Single phase

Fasco Fan & Blower Motors (HVAC/R) D181 - 1/30 HP - 115 V - 1500 RPM - Single phase

Century
$215.00
$215.00
Quantity must be 1 or more
  • Horsepower :1/30
  • Voltage :115
  • Amps :1.30/1.00
  • RPM :1500
  • Frequency :60 Hz
  • "C" Dim. :5.33"
  • Enclosure :Open Air Over
  • Shaft Dim. :5/16" x 2.3"
  • Type :Shaded Pole
  • Speeds :2
  • Diameter :3.3"
  • Bearings :Sleeve
  • Rotation :CCWSE
  • Protector :Thermal
  • Service Factor :1
  • Phase :1
  • Ambient Temp. :40°C
  • Weight (lbs.) :3
  • Century 81. The primary difference is that the leads extend out of the shell on the opposite shaft end, whereas the 81 had the leads on the shaft end

  • References: A.O. Smith 81, Fasco 7163-1654 7163-2279 7163-3024 7163-5376 7163-6985 7190-120, 81U, Universal Electric AA2G095N, Rotom R455
