Fasco Fan & Blower Motors (HVAC/R) D721 - 1/4 HP - 115 V - 1075 RPM - Single phase
Fasco Fan & Blower Motors (HVAC/R) D721 - 1/4 HP - 115 V - 1075 RPM - Single phase

Fasco Fan & Blower Motors (HVAC/R) D721 - 1/4 HP - 115 V - 1075 RPM - Single phase

Fasco
$179.00
$179.00
Quantity must be 1 or more

• HP: 1/4
• Voltage: 115
• RPM: 1075
• Current (Amp): 4.80
• Phase: 1
• Rotation: Reversible
• Frame: 48
• Enclosure: Open Drip Proof
• Speeds: 3
• Protector: Automatic
• Ambient Temp: 40°C
• Service Factor: 1.00
• Shaft Dimensions: 0.500 in X 5.94 in
• Frequency: 60Hz
• Diameter: 5.5 in
• Frame Length: 4.21 in
• Bearings: Sleeve
• Capacitor Rating: 5-44
• Features: class b insulation, 26" leads, extended studs shaft end, resilient ring mounting, belly band mounting (belly band not included), open shaft end and lead end, shell half vented, air over, capacitor required: 5 mfd-370 volts (not supplied with motor)
• Reference : A.O.Smith Century F48F93B22 EM3583 DL1026 130 144 0533, Emerson K55HXCCS1546 K55HXPTK5311 F55HXCBR1216 FA55HXGTD1734, Fasco 7126-0088 7126-0653, General Electric 3583 5KCP39FGN651S 5KCP39KGW279BS, Marathon X000 73080, Universal Electric HA3G009N HA3G652 HA3H006N HA3H018K HA3H652 HA3J026 HA3J026N HE3F060N HE3F212N HE3G040 HE3G041 HE3H002N, K1863, 8716010310 8726310171 8746010201
