• HP: 1/8-1/12
• Voltage: 230
• RPM: 1550
• Current (Amp): 2.0-1.4
• Phase: 1
• Rotation: Reversible
• Frame: 4.4
• Enclosure: Open Air Over
• Speeds: 2
• Protector: Thermally Protected
• Ambient Temp: 40°C
• Service Factor: 1.00
• Shaft Dimensions: 6.50 in X 0.500 in X 6.50 in
• Frequency: 60Hz
• Diameter: 4.4 in
• Frame Length: 4.02 in
• Bearings: Sleeve
• Features: class A insulation, 30" leads, resilient mounting ring lead end and opposite lead end
• Reference : Fasco 7108-0163 7108-2274 7108-2526 7108-5152, Franklin 8414237050
