Leeson Unit Heater Motors (HVAC/R) X302 - 1/6 HP - 115 V - 1625 RPM - Single phase
Leeson Unit Heater Motors (HVAC/R) X302 - 1/6 HP - 115 V - 1625 RPM - Single phase

Leeson Unit Heater Motors (HVAC/R) X302 - 1/6 HP - 115 V - 1625 RPM - Single phase

LEESON
$282.00
$282.00
Quantity must be 1 or more
  • Horsepower :1/6
  • Voltage :115
  • Amps :3.0
  • RPM :1625
  • Frequency :60 Hz
  • "C" Dim. :8.5"
  • Enclosure :Totally Enclosed Air Over
  • Shaft Dim. :1/2" x 2-3/4"
  • Type :Permanent Split Capacitor
  • Speeds :1
  • Frame :48Y
  • Base :Resilient
  • Bearings :Ball
  • Rotation :Reversible
  • Protector :Automatic
  • Service Factor :1.0
  • Phase :1
  • Ambient Temp. :40°C
  • Weight (lbs.) :13

  • Reference : Model 48A11T199M, Carrier HC37DX120, Century US1016
