Leeson Oil Burner Motor (HVAC/R) O600 - 1/8 HP - 115 V - 1725 RPM - Single phase
Leeson Oil Burner Motor (HVAC/R) O600 - 1/8 HP - 115 V - 1725 RPM - Single phase

Leeson Oil Burner Motor (HVAC/R) O600 - 1/8 HP - 115 V - 1725 RPM - Single phase

LEESON
$219.00
$219.00
Quantity must be 1 or more
  • Horsepower :1/8
  • Voltage :115
  • Amps :2.50
  • RPM :1725
  • Frequency :60 Hz
  • Length :5-7/32"
  • "C" Dim. :7-5/32"
  • Enclosure :Open
  • Shaft Dim. :1/2" x 1-13/16"
  • Type :Split Phase
  • Speeds :1
  • Diameter :5-5/8"
  • Frame :48N
  • Bearings :Sleeve
  • Rotation :Reversible
  • Protector :Manual
  • Service Factor :1.00
  • Phase :1
  • Ambient Temp. :40°C
  • Feature(s) :Class 'B' Insulation, Enclosed when mounted, Open shaft end bracket, Equipped with rotation switch for easy reversibility, Equipped with provisions for mounting 4" x 4" conduit box
  • Weight (lbs.) :9
  • Reference : A.O. Smith Century EL2004 EL2005 EL2004V1, Carrier HC35UX116 HC35VA115, Emerson Stock No. 3196, General Electric 4782, Marathon 48A17T286, Universal Electric Stock No. 723
