HP : 1/12
Voltage : 115
RPM : 1625
Current (Amp) : 1.50
Phase : 1
Rotation : Clockwise Shaft End
Frame : 42Y
Enclosure : Totally Enclosed Air Over
Speeds : 1
Protector : Thermally Protected
Ambient Temp : 40°C
Service Factor : 1.00
Shaft Dimensions : 5/16 in X 3.25 in
Frequency : 60Hz
Diameter : 5.0 in
Frame Length : 4.17 in
Bearings : Sleeve
Capacitor Rating : 10 Mfd-370Vac
Reference : A.O. Smith F42E44A41, Emerson K48HXEEY1150 K48HXMRA1176, Fasco 7184-0201, MacMillan AO812B3581
Modine 9F30213 9F30213A, FP 32255:
Replacement Motor.
Alternative part number 9F0302130000, 9F030213.
OEM US Motors K48HXEEY-1150.
Fits These Modine Brand Models:
HD60 Before 5/07 - Hot Surface Ignition, HD60 After 5/07 - Direct Spark Ignition, HD75 Before 5/07 - Hot Surface Ignition, HD75 After 5/07 - Direct Spark Ignition, HDC60, HDC75, HDS60 Before 5/07 - Hot Surface Ignition, HDS60 After 5/07 - Direct Spark Ignition, HDS75 Before 5/07 - Hot Surface Ignition, HDS75 After 5/07 - Direct Spark Ignition
