• HP: 34 Watt
• Voltage: 230
• RPM: 1550
• Current (Amp): 0.80
• Phase: 1
• Rotation: Counterclockwise Shaft End
• Frame: Unit Bearing
• Enclosure: Totally Enclosed Air Over
• Speeds: 1
• Protector: Thermally Protected
• Ambient Temp: 40°C
• Service Factor: 1.00
• Shaft Dimensions: 0.275 in X 0.72 in (Hubless)
• Frequency: 60Hz
• Frame Length: 3.58 in
• Bearings: Sleeve
• Features: class b insulation, shaft with 4 end-stud, 21-23 in leads with ring terminals, one foot, front shroud, 3 tapped rear holes.
• Weight: 6 lbs
• Reference : EC-34W230 EC34W230 NUT6B34PUN201 NU34-45-4/056
