- Horsepower : 1/10
- Amps : 1.40 / 0.70
- Frequency : 60 Hz
- Length : 6-31/32”
- Enclosure : Open
- Shaft Dim. : 1/4" x 3-23/32”
- Type : Permanent Split Capacitor
- Diameter : 3.3”
- Bearings : Ball
- Rotation : Reversible
- Protector : Thermally Protected
- Ambient Temp. : 40°C
- Feature(s) : Class ‘B’ Insulation, Conduit Box, 3 Mounting Lugs, Stainless Steel Shaft 1/4” to 5/16” Bushing
- Weight (lbs.) : 6
