• HP : 1/6
• Voltage : 208-230
• RPM : 825
• Current (Amp) : 1.00
• Phase : 1
• Rotation : Reversible
• Frame : 48YZ
• Enclosure : Totally Enclosed Air Over
• Speeds : 2
• Protector : Automatic
• Ambient Temp : 60°C
• Service Factor : 1.00
• Shaft Dimensions : 0.50 in X 6.00 in
• Frequency : 60Hz
• Diameter : 5.5 in
• Frame Length : 10.92 in
• Bearings : Self-Align
• Capacitor Rating : 5-44
• Features : Class B Insulation, Extended Bolts Opposite Shaft End, Belly Band Mount, 30" Leads, 1/2" Diameter Shaft With Flat, Capacitor Required : 5 Mfd-370 Volts (Not Supplied with Motor)
• Reference : Model # : A.O. Smith F48C78A01 F48SD8MA3 F48SJ68L2 F48SJ8L1 F48SJ8L3, Century FS1018, Emerson K055TCD8221012B, Universal Electric HE4F006
