• HP : 3/4
• Voltage : 115
• RPM : 1075
• Current (Amp) : 10.60
• Phase : 1
• Rotation : Reversible
• Frame : 48Y
• Enclosure : Open Air Over
• Speeds : 4
• Protector : Automatic
• Ambient Temp : 40°C
• CFM :
• Service Factor : 1.00
• Shaft Dimensions : 0.50 in X 5.00 in
• Frequency : 60Hz
• Diameter : 5.5 in
• Frame Length : 10.81 in
• Bearings : Ball
• Capacitor Rating : 15-370
• Features : Class B Insulation, Extended Bolts Shaft End, Belly Band Mount, 36" Leads, 1/2" Diameter Shaft With Flat, Capacitor Required : 15 Mfd-370 Volts (Not Supplied)
• Reference : Manufacturer Model # : K055TDM8416012B
