Fasco Fan & Blower Motors (HVAC/R) - D134 - 1/20 HP - 115 V - 1500 RPM - Single phase
Fasco Fan & Blower Motors (HVAC/R) - D134 - 1/20 HP - 115 V - 1500 RPM - Single phase

Fasco Fan & Blower Motors (HVAC/R) - D134 - 1/20 HP - 115 V - 1500 RPM - Single phase

Fasco
$226.00
$226.00
La quantité doit être supérieure ou égale à 1
  • Type : Shaded Pole
  • HP : 1/20
  • Voltage : 115
  • RPM : 1500
  • Current (Amp) : 1.70
  • Phase : 1
  • Rotation : Clockwise Shaft End
  • Frame : 3.3
  • Enclosure : Totally Enclosed Fan Cooled
  • Speeds : 1
  • Protector : Thermally Protected
  • Ambient Temp : 40°C
  • CFM : N/A
  • Service Factor : 1.00
  • Shaft Dimensions : 5/16 in X 2.30 in
  • Frequency : 60Hz
  • Diameter : 3.3 in
  • Frame Length : 2.57 in
  • Bearings : Sleeve
  • Capacitor Rating : N/A
  • Reference : A.O. Smith 38 83, Electrohome 2868-513-050 2868-513-055 2868-513-125, Fasco 7163-1705 7163-1455, Universal Electric 38U, Universal Electric Model AA2G006 AA2G008 AA2G010 AA2G012 AA2G018 AA2G019 AA2G034 AA2G057 AA2G058 AA2G059 AA2G066 AA2G069 AA2G074 AA2G083 AA2G084N AA2G087 AA2G092 AA2G097 AA2G108 AA2G110 AA2G123 AA2G132 AA2G135 AA2G143 AA2G151 JA2R098 JA2R222 JA2S096 JA2S105
