Horsepower : 1/12
Voltage : 115 / 208-230
Amps : 1.10 / 0.50
RPM : 1550
Frequency : 60/50 Hz
Length : 3-5/8"
Enclosure : Open
Shaft Dim. : 5/16" x 3-1/4"
Type : Permanent Split Capacitor
Speeds : 1
Diameter : 3.3"
Bearings : Ball
Rotation : Reversible
Protector : Automatic
Phase : 1
Ambient Temp. : 40°C
Capacitor Rating : 4MFD-370V
Feature(s) : 50% More Efficient than Shaded Pole Motors, Class 'B' Insulation, Capacitor Included, Includes Lead & Plug Assembly, Reversing Plug, Thru-Bolts
Weight (lbs.) : 5
Reference : JA2P275 , 196242
