ECM Motors (HVAC/R) EC5408 - 1/15 HP - 115/230 V - 1550 RPM - Single phase
ECM Motors (HVAC/R) EC5408 - 1/15 HP - 115/230 V - 1550 RPM - Single phase

ECM Motors (HVAC/R) EC5408 - 1/15 HP - 115/230 V - 1550 RPM - Single phase

US Motors
$221.00
$221.00
Quantity must be 1 or more
  • Horsepower :1/15, 1/20, 1/25
  • Voltage :115/230
  • Amps :0.65-1.20
  • RPM :1550/800
  • Frequency :50/60 Hz
  • Length :2.20"
  • Enclosure :IP67
  • Shaft Dim. :5/16" x 2-1/2"
  • Type :Electronically Commutated
  • Speeds :2
  • Diameter :3.3"
  • Efficiency :up to 70%
  • Bearings :Ball
  • Rotation :Reversible
  • Protector :Automatic
  • Service Factor :1.00
  • Phase :1
  • Ambient Temp. :-40°C to 55°C
  • Feature(s) :Stainless Steel shaft, Class 'A' Insulation, Standard 4 Bolt 10-32 Mounting Studs Each End , Robust Ball Bearing System, Aluminum Low Profile Frame, UL/CUL Approved, Includes 18" Cord & 2-Pin Plug, Operating IP67 Water Tight with all angle Moisture Protection, Dual Voltage: No Connection Change Required
  • Weight (lbs.) :3
  • Reference :5100, 5101, 5102, 5103, 5104, 5105, 5106, 5200, 5201, 5202, 5203, 5204, 5205, 5206, 35100, 35101, 35102, 35103, 35200, 35201, 35202, 35203, 10850, 9209L, 9210L, 9209H, 9210H, 9215L, 9215H, 9216L, 9216H, 9214L, 9214H, M4-R2155, M4-R2156, M4-R2157, M4-R2158, 22617801, 22618001, 25307801, 25308001, 2531194, 22617701, 22617901, 25307701, 25307901, R6350, R6355, R6360, R6365, 05105, 05104, 05205, 05204, 5SME59BVA1038, 5SME59BVA1036, 5SME59BVA2039, 5SME59BVA2037, 10852, 10853, 10854, 10850, FA118A4813, 1108149, KEE1108149, 5010047, 5010047-001
